SP8T Module test system
Module parameters
Scale: SP8T * 8
Bandwidth: DC-18GHz
Impedance: 50 Ω
Insertion loss:<0.3db
Isolation:>80db
Standing wave ratio:<1.2
Switching speed:<50ms
Switching life 2000000
Control interface: Ethernet/serial port
Packaging form: standard 19 inch cabinet installation, 482mm wide * 90mm (2U) high * 600mm deep
System block diagram
Typical test chart
Schematic diagram of chassis
